Gabbioneta Pumps® Termomeccanica Pompe
VI VS4 Type API 610 Centrifugal Pump
Trillium Flow Technologies updated VI pump range builds on the engineering excellence, innovation, and heritage of our Termomeccanica Pompe brand.
The expertise in designing and manufacturing VS4 pumps dates back to the 1970s, with thousands of units installed worldwide. This API-compliant VS4 pump range is a radially split, single-stage, vertically mounted pump with a single suction first stage impeller.
Trillium Flow Technologies utilise a unique construction to minimise the mounting flange diameter to save our customers capital cost of installation.
Key Features
- API 610 compliant
- Compact design to minimise mounting flange diameter
- Standard line shaft options for any sump length
- API 682 compliant seal chamber
- Single suction Impeller
- Wide range of hydraulics for a variety of applications
- Line bearing flush combined with column flanges for more compact and robust design
- Balance line to ensure both seals remain at equal pressure
- Interstage take off options to support bespoke applications
- Tie bolt design to reduce cost and to accommodate thermal shock
Options
- All API material options:
- S-4,S-5,S-6,S-8,C-6,A-8,D-1,D-2, plus bespoke options
- High efficiency options for RO and power markets
- Composite wear parts, for improved efficiency and rotor dynamics
- Specialist Options: high speed over 6500 RPM, Interstage Take off Options
Main Applications
- Boiler feed water for traditional power plants
- Water transmission pipelines & water distribution
- Condensate extraction
- High pressure auxiliary services in general industry, petrochemical & RO desalination plants
